Marel IPM3X300

TECHNICAL DETAILS Dimensions Outer Dimensions 3300 x 900 x 1500 mm , 130'' x 36'' x 59'' (L x W x H) Weight Approx. 1 ton Belt Length 2484 / 5192 med mer / Belt Width 280 mm Opening 3300 x 1700 x 1600 mm, 130'' x 67'' x 63'' (L x W x H)

Capacity : Throughput Up to 1500 kg, 3300 lb of fillets per hour (precut) Rate Up to 8 cuts per second, up to 1200 rpm Belt Speed Motor rated speed: 0.16 m/s, Range: 0.03 - 0.42 m/s Accuracy Salmon fillets: For portions up to 120 g the accuracy is +/- 2-4 g based on 1 standard deviation. For larger portions the accuracy is +/- 1 % to 3 % of portion weight based on 1 standard deviation.

Raw Material: Suitable for Raw material: whitefish or salmon fillets, with or without skin and bones Raw material state: fresh, smoked, water injected, wet salted (standard solution) Piece Size 250 x 150 mm 10'' x 6'' (W x H) Power : Voltage 3 x 380 to 3 x 480 Vac + PE Power Consumption 4 kW Frequency 50/60 Hz Res Current breaker 500 mA
