2006 Low & Duff 500 Kg

Low and Duff chocolate conching machine, 500 kg Capacity.

 Low and Duff 500 mixer/refiner/conche is an exceedingly versatile machine designed for the manufacture of all kinds of chocolate and compounds. It can be used to produce a wide range of products, including those with relatively low fat content formulas. This compact piece of machinery is easy to install, start, and operate. For each batch, it simultaneously grinds the cocoa, and sugar, and thoroughly blends the ingredients, refining them as required. It also conches the resulting chocolate mass. The LOW and DUFF 500 works by means of rotating blades that provide pressure against the inner wall of the working chamber. This working chamber is fitted with grooved sections used by the blades to mix and refine the product as required. The blades are moved by means of a reduction gear that enables maximum energy transfer. The amount of pressure exerted by blades against the grooved sections is determined by means of an electronically controlled and regulated hydraulic motor. The machine is fitted with a double-jacket for heating and cooling. It features a controlled automatic cold water inlet and water pump to ensure an even distribution of operating temperatures.
